Performance, features and value in a super portable package.
Positioned above the ZLX series and below the EKX series, the ELX200 series includes 10", 12" and 15" two-way models, and 12" and 18" subwoofers. All of them are available in powered and passive versions. The ELX200-15 is the passive full-range model with a 15" woofer. The ELX200 series, introduced in 2017, zeroes in on an underserved price point and does so with lightweight cabinets, professional sound and a versatile feature set that makes playing and performing easier than ever. This model is an ideal choice for bands, DJs or venues that use dedicated power amps. The 15" woofer provides all of the low-end punch a dance audience demands.
The full-range models feature low-profile form factors designed with durable composite enclosures to balance light weight, structural integrity and ease of use. The subwoofers pack powerful low-frequency output into a compact footprint, assembled in an optimized 15 mm-thick wooden enclosure with a protective finish.
The features that have made other members of the Electro-Voice portable loudspeaker family a go-to for first-rate sound quality are also present, including powerful-yet-efficient Class-D amplifier design, QuickSmartDSP control and processing, and the SST (Signal Synchronized Transducers) waveguide design. Equipped with suspension points for fixed installation, ELX200 makes it easy to achieve superior results across a wide range of applications, including permanent installation.
The ELX200 series is ideal for bands, DJs, venues and sound-reinforcement rental companies. Whether you are adding subwoofers to an existing system or building your system from the ground up, ELX200 offers an economical, professional solution to the challenges of live-sound reinforcement.
The full-range models feature low-profile form factors designed with durable composite enclosures to balance light weight, structural integrity and ease of use. The subwoofers pack powerful low-frequency output into a compact footprint, assembled in an optimized 15 mm-thick wooden enclosure with a protective finish.
The features that have made other members of the Electro-Voice portable loudspeaker family a go-to for first-rate sound quality are also present, including powerful-yet-efficient Class-D amplifier design, QuickSmartDSP control and processing, and the SST (Signal Synchronized Transducers) waveguide design. Equipped with suspension points for fixed installation, ELX200 makes it easy to achieve superior results across a wide range of applications, including permanent installation.
The ELX200 series is ideal for bands, DJs, venues and sound-reinforcement rental companies. Whether you are adding subwoofers to an existing system or building your system from the ground up, ELX200 offers an economical, professional solution to the challenges of live-sound reinforcement.
Specifications
- Suspension: Three M10 suspension points
- Minimum Impedance: 7 ohms
- HF Transducer: DH-1L 1" titanium compression driver
- Speaker Type: Full-Range
- Woofer Size: 15"
- Frequency Response (-3dB): 77Hz–16kHz
- Frequency Range (-10dB): 52Hz–19kHz
- Max. SPL/1m (calc): 130dB
- Coverage (Nominal -6dB) H: 90°
- LF Transducer: EVS-15M 381 mm (15")
- Coverage (Nominal -6dB) V: 60°
- Power Rating 1,200W
- Crossover Frequency: 1.6 kHz
- Connector Type: Dual NL4
- Enclosure Material: Polypropylene composite
- Grille: 18 AWG steel with powdercoat
- Color: Black
- Height: 27.95" (710 mm)
- Width: 16.65" (423 mm)
- Recommended High-Pass Frequency: 42Hz
- Depth: 15.12" (384 mm)
- Net Weight: 41.23 lb. (18.7 kg)
- Family: ELX200
- Nominal Impedance: 8 ohm
- Axial Sensitivity (SPL, 1 W @ 1 m): 95dB
- Power Handling (Continuous/Peak): 300W/1,200W
Features
- 1,200W (peak), 130dB peak SPL system that is reliability verified with over 500 hours of abuse testing and endurance testing to 4x typical industry practices
- 1.4" DH-1L (1" exit) titanium compression driver for extended transparent high-frequency response
- High-output EVS-15M woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction
- EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading
- Professional-grade hardware: three M10 threaded mounting points for forged eyebolts, integrated pole-mounts and the proven ZLX three-handle design for easy lifting
