Twelve-channel digital mixing system.
The Zoom LiveTrak L-12 is a portable mixing system with great sound and features. Not only can you mix up to 12 individual channels, but you can also create custom headphone mixes for up to five band members and craft a polished live mix complete with studio-quality effects.
You can complete your entire project on the L-12 or transfer all 12 discrete tracks to your DAW for editing and mixing. The LiveTrak L-12 also functions as a 14-in/4-out USB audio interface for your Mac, PC, or iOS device.
Channels 3–8 have a -26dB pad for capturing loud sources, and a clear 12-segment LED metering helps you keep an eye on your levels. You can save up to 9 scenes and recall your custom settings automatically. You can even program the mixer to record automatically when the master fader detects a certain dB level. Capture data up to 2 seconds before recording starts. It includes a built-in slate mic for recording comments or talk back and an onboard metronome for keeping the band in sync.
You can complete your entire project on the L-12 or transfer all 12 discrete tracks to your DAW for editing and mixing. The LiveTrak L-12 also functions as a 14-in/4-out USB audio interface for your Mac, PC, or iOS device.
Channels 3–8 have a -26dB pad for capturing loud sources, and a clear 12-segment LED metering helps you keep an eye on your levels. You can save up to 9 scenes and recall your custom settings automatically. You can even program the mixer to record automatically when the master fader detects a certain dB level. Capture data up to 2 seconds before recording starts. It includes a built-in slate mic for recording comments or talk back and an onboard metronome for keeping the band in sync.
Specifications
Format
- Analog/digital: Digital
- Busses/groups: 4
- Aux sends: Monitor panel
- Powered: No
- Total inputs: 12
- Mic preamps: 8
- XLR/TRS combo jacks: 8
- XLR only jacks: 0
- 1/4" only jacks: 4
- S/PDIF in: No
- ADAT/optical in: No
- RCA in: 2 x Stereo
- AES/EBU: No
- XLR out: 2 (master)
- 1/4 in. out: 2 (monitor)
- S/PDIF out: No
- ADAT/optical out: No
- RCA out: No
- AES / EBU: No
- Connections: USB
- MIDI I/O: No
- Headphone output(s): 1
- USB 1 Type B, 1 Type A
- Onboard effects
- Compression: Yes
- Reverb: Yes
- Delay: Yes
- Chorus/flange: Yes
- Type: Rotary
- EQ bands: 3-Band, low cut
- Master graphic: No
- Width: 17.5 in.
- Height: 2.8 in.
- Depth: 11.1 in.
- Weight: 5.6 lbs.
Features
- 12-channel digital mixer (8 mono/2 stereo) and 14-in/4-out USB audio interface for Mac, PC, or iOS device (Apple Lightning-to-USB Camera Adapter is required for iOS)
- 12-track 24-bit/96kHz recording directly to an SD card, up to 48kHz to a computer and an SD card simultaneously
- Create customizable, savable headphone mixes for up to 5 band members
- Complete your project on the mixer, or transfer all 12 tracks to your DAW for editing
- 8 combo jacks great-sounding mic preamps accommodate both XLR and 1/4" connectors
- Channels 1–2 offer hi-Z inputs for your electric guitar or bass and channels 9/10 and 11/12 have TRS and RCA connectivity for keyboards and other audio devices
- Each channel features a 3-band mid-parametric EQ and 16 built-in effects, while channels 1–8 include a dedicated compressor for controlling dynamics
